PB6100 series pressure transmitter Suppliers

  • Accuracy: 0.5%F·S
  • Measuring range: -0.1...0bar to -1...0bar 0...0.1bar to 0...600bar to -1...25bar 0...1bar to 0...35bar absolute
  • Linearity: superior to 0.25%F·S
  • Stability: superior to 0.25%F·S for 1 year
  • Temperature drift: superior to ± 0.75%(0 to 50℃)
  • Response time: ≤10mS
  • Power supply:12...36VDC
  • Output: 4...20mA (or 1...5V)
  • Load resistance: 0 to 600Ω
  • Proof pressure: 150%F·S
  • Process connection: M20*1.5 or 1/2NPT, Flange , Clamp or customized
  • Electric connection: M20*1.5
  • Protection: IP65
  • Wetted parts: 304 stainless steel
  • Diaphragm material: 316L stainless steel
  • Housing material: cast aluminum
  • Power supply: <0.5W (24VDC)
  • Ambient temp: -20...85℃
  • Storage temp: -45...125℃
About us

Ningbo Qingyang Automation Technology Co., Ltd.

Yuyao Huangong Automation Instruments Factory

Ningbo Qingyang Automation Technology Co., Ltd. is famous China PB6100 series pressure transmitter suppliers and OEM/ODM PB6100 series pressure transmitter manufacturers. We have advanced and complete top-notch testing equipment in the industry, physical testing laboratories, automatic pressure calibration equipment, automatic temperature calibration equipment, wholesale PB6100 series pressure transmitter etc. The above equipment can fully ensure the provision of high-precision final Custom PB6100 series pressure transmitter to customers, and can ensure that customers can meet all-round testing requirements for physical and chemical properties of materials, high-precision geometric dimension testing, etc.

  • 20+

    Years experience

  • 1000+

    Company area

  • 200+

    Team members

  • 30+

    Export country

Honor

News center
Industry knowledge extension of this category
What is PB6100 series pressure transmitter
The PB6100 series pressure transmitter is a type of electronic device that is used to measure the pressure of liquids or gases in various industrial applications.The PB6100 series pressure transmitter uses a piezoresistive sensor technology to convert the pressure signal into an electrical signal, which is then transmitted to a control system or display unit. It is capable of measuring pressure ranges from 0-5 psi up to 0-10,000 psi with high accuracy and stability.
Some of the key features of the PB6100 series pressure transmitter include its rugged design, wide temperature range, high overpressure capability, and various output options such as 4-20mA, voltage, or frequency. These features make it suitable for use in a wide range of applications, including oil and gas, chemical processing, power generation, and water treatment, among others.
Types of PB6100 series pressure transmitter
The PB6100 series pressure transmitter comes in various types that are designed to suit specific applications and pressure ranges. Some of the common types of PB6100 series pressure transmitters are:
1.Differential Pressure Transmitter: This type of pressure transmitter measures the difference in pressure between two points and is used to monitor the flow of liquids or gases in pipelines and other systems.
2.High-Pressure Transmitter: This type of pressure transmitter is designed to measure pressure in high-pressure applications, such as oil and gas drilling, hydraulic systems, and pressure vessels.
3.Low-Pressure Transmitter: This type of pressure transmitter is designed to measure pressure in low-pressure applications, such as air flow measurement in HVAC systems and medical equipment.
Advantages of PB6100 series pressure transmitter
The PB6100 series pressure transmitter offers several advantages that make it a popular choice for many industrial applications. Some of these advantages include:
1.Wide Pressure Range: The PB6100 series pressure transmitter can measure pressure in a wide range of applications, from low-pressure systems to high-pressure systems, providing greater flexibility and versatility.
2.Robust and Durable: The PB6100 series pressure transmitter is built to withstand harsh environments and demanding conditions, making it highly durable and reliable. This reduces maintenance costs and downtime, improving overall system efficiency.
3.Various Output Options: The PB6100 series pressure transmitter offers various output options, such as 4-20mA, voltage, or frequency, making it compatible with a wide range of control systems and instrumentation.
