PB8200 series pressure transmitter Suppliers

  • Accuracy: 0.25%F·S , 0.5%F·S
  • Measuring range: -0.1...0bar to -1...0bar 0...0.1bar to 0...600bar or -1...25bar relative or 0~1bar to 0~35bar absolute
  • Linearity: superior to 0.25%F·S
  • Stability: superior to 0.25%F·S for 1 year
  • Temperature drift: superior to ±0.75%F·S(0 to 50℃)
  • Response time:≤10mS
  • Power supply:12 to 36VDC
  • Output: 4...20mA (or 1...5V)
  • Load resistance: 0~600Ω
  • Proof pressure: 150%F·S
  • Ambient temp: -20...85℃
  • Compensated temp: -20...85℃
  • Process connection: M20*1.5male or 1/2 NPT male,Flange,Clamp or customized
  • Electric connection: M20*1.5male
  • protection: IP65
  • Wetted materials: 304 stainless steel
  • Diaphragm material: 316L stainless steel
  • Housing material: cast aluminum
  • Power consume: <0. 5W (24VDC)
About us

Ningbo Qingyang Automation Technology Co., Ltd.

Yuyao Huangong Automation Instruments Factory

Ningbo Qingyang Automation Technology Co., Ltd. is famous China PB8200 series pressure transmitter suppliers and OEM/ODM PB8200 series pressure transmitter manufacturers. We have advanced and complete top-notch testing equipment in the industry, physical testing laboratories, automatic pressure calibration equipment, automatic temperature calibration equipment, wholesale PB8200 series pressure transmitter etc. The above equipment can fully ensure the provision of high-precision final Custom PB8200 series pressure transmitter to customers, and can ensure that customers can meet all-round testing requirements for physical and chemical properties of materials, high-precision geometric dimension testing, etc.

  • 20+

    Years experience

  • 1000+

    Company area

  • 200+

    Team members

  • 30+

    Export country

Honor

News center
Industry knowledge extension of this category
What is PB8200 series pressure transmitter
The PB8200 series pressure transmitter is a type of industrial sensor used to measure pressure and convert it into an electrical signal. This series of pressure transmitters is designed and manufactured by WIKA, a leading manufacturer of measurement technology.
The PB8200 series pressure transmitter is known for its high accuracy, reliability, and robustness. It is suitable for use in a wide range of industrial applications, including oil and gas, chemical, and petrochemical industries, as well as in process control and automation systems.
The PB8200 series pressure transmitter utilizes a piezoresistive sensor that converts pressure into an electrical signal. This signal is then processed by the transmitter's electronics to provide a highly accurate and reliable output signal proportional to the applied pressure. The transmitter can be configured for various pressure ranges, output signals, and electrical connections to meet the requirements of specific applications.
Use of PB8200 series pressure transmitter
The PB8200 series pressure transmitter can be used in a variety of industrial applications where precise pressure measurements are required. Here are some examples of its use:
1.Oil and gas industry: The PB8200 series pressure transmitter can be used in oil and gas pipelines to measure the pressure of the fluid flowing through the pipeline. This information is essential for ensuring the safe and efficient operation of the pipeline.
2.Chemical industry: The PB8200 series pressure transmitter can be used in chemical processing plants to measure the pressure of gases and liquids used in the production process. This information is necessary for controlling the process and ensuring the quality of the final product.
3.HVAC industry: The PB8200 series pressure transmitter can be used in heating, ventilation, and air conditioning (HVAC) systems to measure the pressure of air flowing through the ducts. This information is essential for ensuring the efficient operation of the HVAC system and maintaining indoor air quality.
Advantages of PB8200 series pressure transmitter
The PB8200 series pressure transmitter has several advantages that make it a popular choice for industrial pressure measurement applications. Here are some of the advantages of this series of pressure transmitters:
1.Robust construction: The PB8200 series pressure transmitter is built to withstand harsh industrial environments. It is constructed with high-quality materials that can withstand extreme temperatures, pressure spikes, and vibration.
2.Easy to install and maintain: The PB8200 series pressure transmitter is designed to be easy to install and maintain. It is available with a variety of electrical connections and mounting options, making it easy to integrate into different systems. Its modular design also allows for easy maintenance and repair.
3.Configurable output signals: The PB8200 series pressure transmitter can be configured to provide a variety of output signals, including analog and digital signals, making it compatible with different types of control systems.
