PB8300 series pressure transmitter Suppliers

PB8000 series diffused silicon pressure transmitter is a practical and compact pressure transmitter. It uses high-precision, high-stability and high-reliability diffused silicon pressure sensing elements to measure liquid or gas pressure and various On-site remote pressure and liquid level measuring instruments that convert the pressure or liquid level into standard electrical signals, are mainly used for mechanical equipment and other occasions with small installation space, and use a unique junction box for installation and maintenance. Convenient, because of its excellent performance, it can replace high-performance imported pressure transmitters.
  • Accuracy: 0.5%F·S
  • Measuring range: -0.1...0bar to -1...0bar 0...0.1bar to 0...600bar to -1...25bar relative 0...1bar to 0...35bar absolute
  • Linearity: superior to 0.25%F.S
  • Stability: superior to 0.25%F.S
  • Temperature drift: superior to +0.75%F.S(0...50℃)
  • Response time: ≤10mS
  • Power supply: 24VDC or (12VC...36VDC optional)
  • Output: 4...20mA (or 1...5V)
  • Load resistance: 0-600Ω
  • Proof pressure: 150%F.S
  • Ambient temp: -20...85℃
  • Compensated temp: -20...85℃
  • Storage temp: -45...125℃
  • Process connection: 1/4BSP
  • Wetted parts: 304 stainless steel
  • Diaphragm Material: 316L stainless steel
  • Housing Material: 304 stainless steel or 316 stainless steel
  • Power Consume: <0.5W (24VDC)
About us

Ningbo Qingyang Automation Technology Co., Ltd.

Yuyao Huangong Automation Instruments Factory

Ningbo Qingyang Automation Technology Co., Ltd. is famous China PB8300 series pressure transmitter suppliers and OEM/ODM PB8300 series pressure transmitter manufacturers. We have advanced and complete top-notch testing equipment in the industry, physical testing laboratories, automatic pressure calibration equipment, automatic temperature calibration equipment, wholesale PB8300 series pressure transmitter etc. The above equipment can fully ensure the provision of high-precision final Custom PB8300 series pressure transmitter to customers, and can ensure that customers can meet all-round testing requirements for physical and chemical properties of materials, high-precision geometric dimension testing, etc.

  • 20+

    Years experience

  • 1000+

    Company area

  • 200+

    Team members

  • 30+

    Export country

Honor

News center
Industry knowledge extension of this category
What is PB8300 series pressure transmitter
The PB8300 series pressure transmitter utilizes a piezoresistive measuring element that converts the pressure applied to it into an electrical signal. The electrical signal is then processed and amplified by the transmitter's electronic circuitry to provide an accurate and reliable output signal proportional to the applied pressure.
The PB8300 series pressure transmitter is known for its high accuracy, stability, and reliability, and is commonly used in a wide range of applications, including process control, machine building, hydraulics, pneumatics, HVAC, and many others. It is also available in a variety of pressure ranges and electrical output options, making it highly customizable to meet specific application requirements.
Use of PB8300 series pressure transmitter
The PB8300 series pressure transmitter is used to measure and monitor pressure in various industrial and commercial applications. Some common uses of this pressure transmitter include:
1.Process Control: The PB8300 series pressure transmitter is often used in industrial process control systems to monitor and regulate pressure levels in pipelines, tanks, and other vessels. This helps ensure that the process operates safely and efficiently, with minimal downtime and waste.
2.Machine Building: The PB8300 series pressure transmitter is commonly used in machine building applications to measure and control pressure in hydraulic and pneumatic systems. This helps ensure that the machines operate reliably and efficiently, with minimal downtime and maintenance.
3.Water Treatment: The PB8300 series pressure transmitter is used in water treatment applications to monitor pressure in water treatment plants, reservoirs, and distribution systems. This ensures that the water supply remains safe and reliable, with minimal waste and contamination.
Advantages of PB8300 series pressure transmitter
The PB8300 series pressure transmitter offers several advantages over traditional mechanical pressure measurement devices, including:
1.High Accuracy: The PB8300 series pressure transmitter utilizes advanced electronic circuitry and piezoresistive sensing technology to provide highly accurate pressure measurements. This makes it ideal for use in applications where precise pressure control is critical.
2.Wide Pressure Range: The PB8300 series pressure transmitter is available in a wide range of pressure ratings, from vacuum up to several thousand psi. This makes it suitable for use in a wide range of industrial and commercial applications.
3.Digital Output: The PB8300 series pressure transmitter provides a digital output signal that can be easily integrated with process control systems and other electronic devices. This allows for easier and more accurate pressure monitoring and control.
